Outdoor Integrated Long Range Passive Rfid Reader UHF 860-960MHz Free SDK

SUNSHINE RFID Technology Co.,Limited
Contact Now

Outdoor Integrated Long Range Passive Rfid Reader UHF 860-960MHz Free SDK

Brand Name : SUNSHINE

Model Number : F5009

Certification : CE.ROSH

Place of Origin : CHINA

MOQ : 1

Payment Terms : T/T, Western Union

Packaging Details : Carton

Tag Protocol : EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C

Working Frequency : 840~960 MHz

Receiving Sensitivity : -82dBm

Multi-tags Reading : ≥400tags/s

Antenna Type : 9dbi circular polarization antenna

RF Port Standing Wave : ≤1.5

Contact Now

Outdoor Integrated Long Range Passive Rfid Reader UHF 860-960MHz Free SDK

Free SDK Outdoor 860-960MHz Long Range Integrated UHF RFID Reader with Built-in 9dBi Antenna ​

Details of Integrated long range UHF RFID Reader F5009-H

*Self-intellectual property
*Support ISO18000-6C (EPC C1G2) protocol tag
*840~868MHz/902~928MHz frequency band (frequency customization optional)
*FHSS or Fix Frequency transmission
*RF output power up to 30dbm (adjustable)
*9dbi antenna optional with effect distance up to 10m (adjustable)
*Support command, polling and trigger mode
*Low power dissipation with single +12 DC power supply
*Support RS232, RS485, RJ45, Wiegand interface and WiFi optional
*Support EPC, TID and USER inventory
*With optional Built-in relay, support NC/NO control
*Support EPC storage with software.

Product Electrical Parameters

NO. Name Parameters
1 Working Voltage DC +12V
2 Working Temperature -25~+65℃
3 Working Humidity ≤95%(+25℃)
4 Storage Temperature -40~+80℃
5 Tag Protocol EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C
6 Working Frequency 840~960 MHz
7

Supporting Working
Areas

China 1, China 2
US, Canada and other regions following U.S. FCC
Europe and other regions following ETSI EN 302
208 with & without LBT regulations
Japan
Korea
Malaysia
Taiwan

8 Output Power Software adjustable, step interval 1.0dB, maximum +30dBm
9 Output Power Flatness ±0.2dBm
10 Receiving Sensitivity -82dBm
11 RF Port Standing Wave ≤1.5
12 Reading Distance ≥14m(relate to tags type, transmitted power and application environment)
13 Multi-tags Reading ≥400tags/s
14 Interface Communication Rate 115200bps
15

Working Temprature
Detection

Support
16 Intensive Read/Write Mode DRM Support
17

Antenna Connection
Protection

Support
18 RSSI Support
19 Antenna Type 9dbi circular polarization antenna
20 Communication Port RS485,RS232(DB-9)RJ45(100M Ethernet port)
21 Buzzer Yes
22 Enclosure ABS industrial plastic case
23 Dimension 28*28*7.5CM
24 IP Grade IP64



Outdoor Integrated Long Range Passive Rfid Reader UHF 860-960MHz Free SDK


Outdoor Integrated Long Range Passive Rfid Reader UHF 860-960MHz Free SDK
